DRONE HUNTER 5BQ

Drone Hunter 5BQ is an aircraft-mounted type RF Jammer system that neutralizes a single drone or multiple drones approaching controlled airspace up to 1km.

Home » PRODUCTS & SOLUTIONS » C-UAS solutions » NEUTRALIZATION » AIRCRAFT-MOUNTED TYPE » DRONE HUNTER 5BQ
C-UAS solutions
C-IED solutions

Aircraft-mounted type

DRONE HUNTER 5BQ

DRONE HUNTER 5BQ

Drone Hunter 5BQ is an aircraft-mounted type jammer with an intuitive design for quick on-site responses to drone threats. It effectively neutralizes the frequencies of either a single drone or multiple drones approaching controlled airspace, including the ISM band and GNSS L1 & L2, up to a distance of 1 km.

Device is certified with an IP65 rating, ensuring optimal performance even in dusty and rainy environments. Additionally, It can be easily mounted on various platforms, including helicopters, airplanes, and UAVs, offering exceptional ease of use.

DRONE HUNTER 5BQ

Features

Jamming Frequency
coverages

ISM 2.4 & 5.8GHz
GNSS L1 , L2, L5

Integrated
Design

Main Module and Antenna

Jamming
Range

Up to 1 km

User-friendly
design

Meet international IEEE/IEC62705-1 & SAR (Specific Absorption Rate) standard IP65

Specifications

Parameter

Value

Frequency Band

2.4GHz ISM : 2,400 - 2,483.5MHz / 83.5MHz (B/W)
5.8GHz ISM : 5,725 - 5,850MHz / 125MHz (B/W)
GNSS L1 : 1,559 ~ 1,610MHz / 51 MHz (B/W)
GNSS L2 : 1,215 - 1,300MHz / 85MHz (B/W)
GNSS L5 : 1, 164 - 1,215MHz / 51 MHz (B/W)

Jamming Range

1km

Operating Temperature

-20° C ~ ＋50° C

Operation Time

1 hour (unlimited use with battery charger attached)

Battery Spec1ficat1on

Rechargeable Lith1um-1on Battery (1 O.OAh)

Ingress Protection

IP65

Dimensions

BACKPACK : 436 x 243 x 151 mm / GUN : 880 x 153 x 187mm

Weight

BACKPACK : 20kg / GUN : 4kg

Product composit1on

BACKPACK & GUN

ANTENNA

– A directional radiation pattern, which enables the concentration of radiation power in a specific direction
– Electrical performance improvement through optimization of multi-band radiation characteristics
– Possession of integrated component development technology and implementation of miniaturization
– Individual implementation of radiation components by frequency band (easy modification of electrical performance by frequency band, convenient response to customer requirements, excellent maintainability, and individual component interchangeability)

Application area

  • national critical infrastructure
  • multi-use facilities
  • VIP protection
national critical infrastructure

national critical infrastructure

Protect national critical infrastructure, including energy and key industrial infrastructure, also border areas requiring security and protection, such as military bases, prisons, etc

multi-use facilities

multi-use facilities

Protect multi-use facilities exposed to threats such as airport and stadiums to prevent human casualties

VIP protection

VIP protection

Protect vehicles and embassy facilities as a means of protecting VIPs
